HITACHI TF08D304VM0A1 LCD

Specification

Model P/N:TF08D304VM0A1
Brand:HITACHI
Diagonal Size:3.0"
Resolution:240(RGB)×400, WQVGA 155PPI
Brightness:0 cd/m²
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , COG
Pixel Format:RGB Vertical Stripe
Active Area:39.24(W)×65.4(H) mm
Bezel Opening:-
Response Time:35 (Typ.)(Tr+Td)
Outline Size:42.64(W)×72.55(H) ×0.89(D) mm
Surface:Antiglare (Haze 42%)
Best View on:Symmetry
Display Colors:16.7M 60% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:6.20g (Typ.)
Application:Mobile Phone
Input Voltage:2.6/3.0V (Typ.)(VDD3/VCI)
Driver IC:COG Built-in S6D04D1X21
Glass Depth:0.30+0.30 mm
Transmissivity:6.3% (Typ.)(with Polarizer)
