Kyocera TCG075VGLDB-G00 LCD

Specification

Model P/N:TCG075VGLDB-G00
Brand:Kyocera
Diagonal Size:7.5"
Resolution:640(RGB)×480, VGA 107PPI
Brightness:200 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥5)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:151.68(W)×113.76(H) mm
Bezel Opening:156.3(W)×118.4(H) mm
Response Time:15/20 (Typ.)(Tr/Td)
Outline Size:173(W)×133(H) ×7.8(D) mm
Surface:Antiglare, Hard coating (2H)
Best View on:-
Display Colors:262K 52% NTSC
Lamp Type:4 strings WLED , 40K hours , Without Driver
Frequency:60Hz
Touch Screen:4-wire Resistive Touch
Panel Weight:265g (Typ.)
Application:Industrial
Signal Interface:Parallel RGB (1 ch, 6-bit) , 40 pins Connector
Input Voltage:3.3V (Typ.)
