TCG043WQLBAANN-GN50 Kyocera LCD panel replacement

Brand：Kyocera
Diagonal Size：4.3 inch
Pixel Format：480(RGB)×272[WQVGA]
Active Area：95.04(H)×53.856(V) mm
Bezel Area：98.7(H)×57.5(V) mm
Luminance：800 cd/m2 (Typ.)
View Direction：-
Viewing Angle：70/70/60/65 (Typ.)(CR≥10)
Support Color：16.7M 46% (CIE1931)
Weight：75.0g
Frame Rate： 60Hz
Model：TCG043WQLBAANN-GN50
Type：a-Si TFT-LCD , LCM
Configuration：RGB Vertical Stripe
Outline Dim.： 105.5(H)×67.2(V)×6.1(D)mm
Treatment：Glare (Haze 0%)
Contrast Ratio： 350:1 (Typ.) (TM)
Response Time：25 (Typ.)(Tr+Td)
Operating Mode： TN, Normally White, Transmissive
Light Source： WLED, 100K hours , W/O Driver
Designed For： Industrial Application,
Touch Panel：Without
Interface Type： 40 pinsParallel RGB (1 ch, 8-bit), FPC
Power Supply： 3.3V (Typ.)
Environment： Operating Temperature: -20 ~ 70 °C; Storage Temperature: -30 ~ 80 °C
