TIANMA TA059XXWF01 LCD

Specification

Model P/N:TA059XXWF01
Brand:TIANMA
Diagonal Size:5.9"
Resolution:1125×2436
Brightness:520 cd/m² (Typ.)
Contrast Ratio:100000:1 (Min.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:AM-OLED, OLED , Full Module
Pixel Format:Sub-Pixel Rendering
Active Area:62.325(W)×134.954(H) mm
Bezel Opening:-
Response Time:1 (Max.)(Tr+Td)
Outline Size:64.525(W)×232.11(H) ×0.4(D) mm
Surface:-
Best View on:Symmetry
Display Colors:16.7M 104% NTSC
Lamp Type:self
Frequency:-
Touch Screen:Without
Panel Weight:TBD
Application:Mobile Phone
Signal Interface:MIPI (4 data lanes) , 38 pins Connector
Input Voltage:1.8/3.0V (Typ.)(VDDI/VDD)
Driver IC:Built-in RM69351
