T320HVN02.0 CELL AUO LCD panel replacement for TV Sets

Brand：AUO
Model：T320HVN02.0 CELL
Diagonal Size：31.5 inch
Type：a-Si TFT-LCD ， CELL
Pixel Format：1920(RGB)×1080[FHD]
Configuration：RGB Vertical Stripe
Active Area：698.4(H)×392.85(V) mm
Outline Dim.：717.585(H)×407.886(V)×1.4(D) mm
Bezel Area：-
Treatment：Antiglare (Haze 2%)， Hard coating (3H)
Luminance：0 cd/m2
Contrast Ratio：4000:1 (Typ.) (TM)
View Direction：Symmetry
Response Time：6.5 (Typ.)(G to G)
Viewing Angle：89/89/89/89 (Typ.)(CR≥10)
Operating Mode：AMVA3， Normally Black， Transmissive
Plate Thickness：0.50+0.50 mm
Transmittance：4.7% (Typ.)(with Polarizer)
Support Color：1.07B
Light Source：No B/L
Weight： TBD
Designed For： TV Sets,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 51 pinsLVDS (2 ch， 8-bit)， Connector
Power Supply：12.0V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
