AUO T260XW02 V5 LCD

Specification

Model P/N:T260XW02 V5
Brand:AUO
Diagonal Size:26.0"
Resolution:1366(RGB)×768, WXGA 60PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:88/88/88/88 (Typ.)(CR≥10)
Color Depth:16.7M 72% NTSC
Backlight:8 pcs CCFL , 60K hours , With Inverter
Signal Type:LVDS (1 ch, 8-bit) , 30 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:575.769(W)×323.712(H) mm
Bezel Opening:580.8(W)×328.8(H) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:500 cd/m² (Typ.)
Outline(mm):626 × 373 × 48.4 (H×V×D)
Response:15/5 (Typ.)(Tr/Td), 8 (Typ.)(G to G) ms
Good View at:Symmetry
Work Mode:VA, Normally Black, Transmissive
Mass:4.20Kgs (Typ.)
Used for:TV Sets
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
