T216XW01 V0 AUO LCD panel replacement for TV Sets

Brand：AUO
Model：T216XW01 V0
Diagonal Size：21.6 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1366(RGB)×768[WXGA]
Configuration：RGB Vertical Stripe
Active Area：477.417(H)×268.416(V) mm
Outline Dim.：501(H)×297(V) mm
Bezel Area：481.0(H)×272.5(V) mm
Treatment：Antiglare (Haze 11%), Hard coating (3H)
Luminance：350 cd/m2 (Typ.)
Contrast Ratio：2000:1 (Typ.) (TM)
View Direction：Symmetry
Response Time：6.5 (Typ.)(Tr+Td)
Viewing Angle：88/88/88/88 (Typ.)(CR≥10)
Operating Mode：VA, Normally Black, Transmissive
Support Color：16.7M 72%(CIE1931)
Light Source：CCFL[4 pcs], 30K hours, W/O Driver
Weight： 3.00Kgs (Max.)
Designed For： TV Sets,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 30 pinsLVDS (1 ch, 8-bit), Connector
Power Supply：5.0V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
