AUO T215HVN05.0 CELL LCD

Specification

Model P/N:T215HVN05.0 CELL
Brand:AUO
Diagonal Size:21.5"
Resolution:1920(RGB)×1080, FHD 102PPI
Brightness:0 cd/m²
Contrast Ratio:3000:1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:476.064(W)×267.786(H) mm
Bezel Opening:-
Response Time:13/5 (Typ.)(Tr/Td), 28 (Typ.)(G to G)
Outline Size:483.864(W)×278.386(H) ×1.41(D) mm
Surface:Antiglare, Hard coating (3H)
Best View on:Symmetry
Display Colors:16.7M 76% NTSC
Lamp Type:No B/L
Frequency:75Hz
Touch Screen:Without
Panel Weight:415g (Typ.)
Application:Desktop Monitor ，TV Sets
Signal Interface:LVDS (2 ch, 8-bit) , 30 pins Connector
Input Voltage:5.0V (Typ.)
Driver IC:COFBuilt-in 6 source chips
Glass Depth:0.50+0.50 mm
Transmissivity:3.6% (Typ.)(with Polarizer)
