OPTREX T-55579GD080J-LW-AAN LCD

Specification

Model P/N:T-55579GD080J-LW-AAN
Brand:OPTREX
Diagonal Size:8.0"
Resolution:800(RGB)×480, WVGA 116PPI
Contrast Ratio:900 : 1 (Typ.) (TM)
Viewing Angle:40/40/40/40 (Typ.)(CR≥50)
Color Depth:262K 68% NTSC
Backlight:7S2P WLED , 50K hours , No Driver
Signal Type:Parallel RGB (1 ch, 6-bit) + SPI , 50 pins FPC
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:174(W)×104.4(H) mm
Bezel Opening:178.6(W)×109.0(H) mm
Treatment:Antiglare (Haze 9%)
Luminance:500 cd/m² (Typ.)
Outline(mm):190 × 120.36 × 13.2 (H×V×D)
Response:15/16 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:460g (Max.)
Used for:Industrial
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
