OPTREX T-55399D084J-FW-A-ABN LCD

Specification

Model P/N:T-55399D084J-FW-A-ABN 1
Brand:OPTREX
Diagonal Size:8.4"
Resolution:640(RGB)×480, VGA 95PPI
Contrast Ratio:600 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/60 (Typ.)(CR≥10)
Color Depth:262K 41% NTSC
Backlight:2 pcs CCFL , 50K hours , No Driver
Signal Type:CMOS (1 ch, 6-bit) , Connector 31 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:170.88(W)×128.16(H) mm
Bezel Opening:174.9(W)×132.2(H) mm
Treatment:Antiglare, Hard coating (2H)
Luminance:480 cd/m² (Typ.)
Response:4/12 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:350g (Typ.)
Used for:Industrial
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C
Outline (mm):199.5×149×12 (H×V×D)
