HITACHI SX25S004 LCD

Specification

Model P/N:SX25S004
Brand:HITACHI
Diagonal Size:10.0"
Resolution:800(RGB)×600, SVGA 100PPI
Contrast Ratio:50 : 1 (Typ.) (TM)
Viewing Angle:40 (Typ.)(CR≥2, Φ2-Φ1)
Color Depth:Color 36% NTSC
Backlight:1 pcs CCFL , No Driver
Signal Type:Parallel Data (2ch, 8-bit) , 40 pins Connector
Panel Type:CSTN-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:202.8(W)×152.1(H) mm
Bezel Opening:207.0(W)×156.0(H) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:100 cd/m² (Typ.)
Outline(mm):236 × 168 × 6.3 (H×V×D)
Response:170/130 (Typ.)(Tr/Td) ms
Good View at:12 o'clock
Work Mode:STN, Normally Black, Transmissive
Mass:330g (Typ.)
Used for:Industrial
Refresh Rate:120Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 5 ~ 40 °C
