TRULY RS0114-Z0 LCD

Specification

Model P/N:RS0114-Z0
Brand:TRULY
Diagonal Size:6.2"
Resolution:720(RGB)×1520 270PPI
Brightness:0 cd/m²
Contrast Ratio:1500:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:67.608(W)×142.728(H) mm
Bezel Opening:-
Response Time:35 (Max.)(Tr+Td)
Outline Size:69.608(W)×148.328(H) ×0.3(D) mm
Surface:-
Best View on:Symmetry
Display Colors:16.7M 70% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:In-Cell Touch
Panel Weight:TBD
Application:Mobile Phone
Driver IC:NoSuggest ILI9883A, TD4160, FT8057, NT36528, ICNL9916
Glass Depth:0.15+0.15 mm
Transmissivity:-
