BOE QV185FHB-N83 LCD

Specification

Model P/N:QV185FHB-N83
Brand:BOE
Diagonal Size:18.5"
Resolution:1920(RGB)×1080, FHD 119PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Color Depth:16.7M 72% NTSC
Backlight:No B/L
Signal Type:eDP (2 Lanes) , eDP1.4 , 30 pins Connector
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:408.96(W)×230.04(H) mm
Bezel Opening:-
Treatment:Antiglare (Haze 25%), Hard coating (3H)
Luminance:0 cd/m²
Outline(mm):422.2 × 244.1 × 1.22 (H×V×D)
Response:14 (Typ.)(G to G) ms
Good View at:Symmetry
Work Mode:HADS, Normally Black, Transmissive
Mass:330g (Typ.)
Used for:Digital Signage
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Driver IC list:Built-in COF 3 source chips
Transmissivity:3.7% (Typ.)(with Polarizer)
Glass Thickness:0.40+0.50 mm
