BOE QV156FHM-N83 LCD

Specification

Model P/N:QV156FHM-N83
Brand:BOE
Diagonal Size:15.6"
Resolution:1920(RGB)×1080, FHD 141PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 98% sRGB
Backlight:10S6P WLED , 20K hours , With LED Driver
Signal Type:eDP (2 Lanes) , eDP1.4b , HBR1 (2.7G/lane) , Connector 30 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:344.16(W)×193.59(H) mm
Bezel Opening:-
Treatment:Glare (Haze 0%)
Luminance:500 cd/m² (Typ.)
Response:30 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:ADS, Normally Black, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):350.66×205.84×4.6 (H×V×D)
Outline Shape:Slim (PCBA Bent, T≤3.0mm)
