QD13WL02 Rev.01 QDI LCD panel replacement for Touch Panel

Brand：QDI
Model：QD13WL02 Rev.01 (QDS001E) 1 Compatible
Diagonal Size：13.0 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1280(RGB)×768[WXGA]
Configuration：RGB Vertical Stripe
Active Area：284.2(H)×170.5(V) mm
Outline Dim.：299(H)×184.5(V) mm
Bezel Area：287.16(H)×173.5(V) mm
Treatment：Glare (Haze 0%), Hard coating (3H)
Luminance：200 cd/m2 (Typ.)
Contrast Ratio：350:1 (Typ.) (TM)
View Direction：6 o’clock
Response Time：5/20 (Typ.)(Tr/Td)
Viewing Angle：45/45/15/35 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K
Light Source：CCFL[1 pcs], 10K hours, W/O Driver
Form Style： –
Designed For： Laptop,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 30 pinsLVDS (1 ch, 6-bit), Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -25 ~ 60 °C
