Chimei Innolux Q070LRE-L81 LCD

Specification

Model P/N:Q070LRE-L81 1
Brand:Chimei Innolux
Diagonal Size:7.0"
Resolution:1024(RGB)×600, WSVGA 169PPI
Brightness:350 cd/m² (Typ.)
Contrast Ratio:700:1 (Typ.) (TM)
Viewing Angle:75/75/75/70 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:153.6(W)×90(H) mm
Bezel Opening:156.4(W)×92.8(H) mm
Response Time:10/15 (Typ.)(Tr/Td)
Outline Size:167.25(W)×104.65(H) ×2.9(D) mm
Surface:Glare (Haze 0%)
Best View on:12 o'clock
Display Colors:262K/16.7M
Lamp Type:4S6P WLED , 20K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:100g (Max.)
Application:Pad & Tablet ，Portable Navigation ，Digital Photo Frame ，Portable DVD Player ，MID UMPC
Signal Interface:LVDS (1 ch, 6/8-bit) , 39 pins FPC
Input Voltage:3.3V (Typ.)
