Innolux PJ055SA-03A LCD

Specification

Model P/N:PJ055SA-03A
Brand:Innolux
Diagonal Size:5.5"
Resolution:1080(RGB)×1920, FHD 403PPI
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Min.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:68.04(W)×120.96(H) mm
Bezel Opening:-
Outline Dim:70.44(H)×128.06(V) ×0.4(D) mm
Treatment:-
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:IPS, Normally Black, Transmissive
Support Color:16.7M 70% NTSC
Light Source:No B/L
Weight:-
Designed For:Mobile Phone
Frame Rate:60Hz
Touch Panel:Without
Plate Thickness:0.20+0.20 mm
Transmittance:3.2% (Typ.)
D-IC Detail:COG Suggest NT35521
