Innolux PJ055IA-14A LCD

Specification

Model P/N:PJ055IA-14A
Brand:Innolux
Diagonal Size:5.5"
Resolution:1080(RGB)×1920, FHD 403PPI
Contrast Ratio:1300:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:68.04(W)×120.96(H) mm
Bezel Opening:-
Outline Dim:70.44(H)×127.31(V) ×0.4(D) mm
Treatment:Without Polarizer
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:AAS, Normally Black, Transmissive
Support Color:16.7M 70% NTSC
Light Source:No B/L
Weight:TBD
Designed For:Mobile Phone
Frame Rate:60Hz
Touch Panel:Without
Interface Type:MIPI
Plate Thickness:0.20+0.20 mm
Transmittance:3.0% (Typ.)
D-IC Detail:COG Suggest NT35532, NT35531, OTM1903
