PVI PD080SX1 LCD

Specification

Model P/N:PD080SX1
Brand:PVI
Diagonal Size:8.0"
Resolution:800(RGB)×600, SVGA 125PPI
Contrast Ratio:420:1 (Typ.) (TM)
Viewing Angle:60/60/35/50 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:162(W)×121.5(H) mm
Bezel Opening:165.0(W)×124.5(H) mm
Outline Dim:200(H)×152(V) ×10.8(D) mm
Treatment:Antiglare
Luminance:420 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:15/25 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K
Light Source:CCFL [2 pcs] , 50K hours , W/O Driver
Weight:322±15g
Designed For:Industrial ，Automotive Display ，Digital Photo Frame ，Portable DVD Player
Frame Rate:60Hz
Touch Panel:Without
Interface Type:TTL/RSDS (1 ch, 6-bit) , 60 pins FPC
Power Supply:3.3/3.3/7.7/15.5/-5.5V (Typ.)(VCC/VDD1/VDD2/VGG/VEE)
