PD035OX4 E Ink LCD panel replacement for Touch Panel

Brand：PVI
Model：PD035OX4
Diagonal Size：3.5 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：320(RGB)×234
Configuration： RGB Delta
Active Area：71.6(H)×52.65(V) mm
Outline Dim.：84.03(H)×65.24(V)×3.73(D) mm
Bezel Area：74.6(H)×55.65(V) mm
Treatment：Antiglare
Luminance：250 cd/m2 (Typ.)
Contrast Ratio： 400:1 (Typ.) (TM)
View Direction：6 o’clock
Response Time：15/25 (Typ.)(Tr/Td)
Viewing Angle：60/60/35/45 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：16.7M
Light Source：WLED[3S2P], 30K hours, W/O Driver
Weight： 42.0±5.0g
Designed For： Digital Still Camera, Digital Video Camera,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 60 pinsDigital RGB (8/24-bit), CCIR601/656, FPC
Power Supply：3.3/3.3/5.0/15/-15V (Typ.)(VCC/VDD1/VDD2/VGH/VEE)
Environment： Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C
