PVI PA050XU2 LCD

Specification

Model P/N:PA050XU2
Brand:PVI
Diagonal Size:5.0"
Resolution:320(RGB)×234 79PPI
Contrast Ratio:350:1 (Typ.) (TM)
Viewing Angle:50/50/15/35 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOG
Pixel Format:RGB Vertical Stripe
Active Area:102.72(W)×74.53(H) mm
Bezel Opening:-
Outline Dim:115.32(H)×87.63(V) ×1.9(D) mm
Treatment:Antiglare
Luminance:0 cd/m²
View Direction:6 o'clock
Response Time:15/30 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:Full color
Light Source:No B/L
Weight:36.0±5.0g
Designed For:Automotive Display ，Digital Photo Frame ，Portable DVD Player ，Video Door Phone
Frame Rate:-
Touch Panel:Without
Interface Type:TFT Specific Analog RGB , 30 pins FPC
Power Supply:3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD/AVDD/VGH/VGL)
Plate Thickness:0.70+0.70 mm
Transmittance:8.5% (Typ.)(with Polarizer)
D-IC Detail:COG Built-in 2 source + 1 gate chips
