AUO P215HVN02.1 LCD

Specification

Model P/N:P215HVN02.1
Brand:AUO
Diagonal Size:21.5"
Resolution:1920(RGB)×1080, FHD 102PPI
Contrast Ratio:3000 : 1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Color Depth:16.7M 72% NTSC
Backlight:15S4P WLED , 30K hours , No Driver
Signal Type:LVDS (2 ch, 8-bit) , 30 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:478.656(W)×260.28(H) mm
Bezel Opening:481.9(W)×263.5(H) mm
Treatment:Antiglare (Haze 25%), Hard coating (3H)
Luminance:300 cd/m² (Typ.)
Outline(mm):501.88 × 284.78 × 12 (H×V×D)
Response:20 (Typ.)(G to G) ms
Good View at:Symmetry
Work Mode:VA, Normally Black, Transmissive
Mass:1.70Kgs (Typ.)
Used for:Digital Signage
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
