BOE NV156FHM-N47 LCD

Specification

Model P/N:NV156FHM-N47 9
Brand:BOE
Diagonal Size:15.6"
Resolution:1920(RGB)×1080, FHD 141PPI
Brightness:250 cd/m² (Typ.)
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:344.16(W)×193.59(H) mm
Bezel Opening:-
Response Time:30 (Typ.)(Tr+Td)
Outline Size:350.76(W)×223.8(H) ×3.2(D) mm
Surface:Antiglare
Best View on:Symmetry
Display Colors:262K 45% NTSC
Lamp Type:10S4P WLED , 15K hours , With LED Driver
Frequency:60Hz
Touch Screen:Without
Application:Laptop
Signal Interface:eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector
Input Voltage:3.3V (Typ.)
Shape Style:Slim (PCBA Flat, T≤3.2mm)
