BOE NV153WUM-T41 LCD

Specification

Model P/N:NV153WUM-T41
Brand:BOE
Diagonal Size:15.3"
Resolution:1920(RGB)×1200, WUXGA 148PPI
Contrast Ratio:1200:1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:329.472(W)×205.92(H) mm
Bezel Opening:-
Outline Dim:334.47(H)×234.42(V) ×3(D) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:300 cd/m² (Typ.)
View Direction:Symmetry
Response Time:20 (Typ.)(Tr+Td)
Operating Mode:ADS, Normally Black, Transmissive
Support Color:16.2M 45% NTSC
Light Source:WLED [12S6P] , 15K hours , With LED Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:On-Cell Touch, I²C
Interface Type:eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 40 pins Connector
Power Supply:3.3V (Typ.)
Form Style:Slim (PCBA Flat, T≤3.2mm)
