BOE NV140FHM-N4W LCD

Specification

Model P/N:NV140FHM-N4W
Brand:BOE
Diagonal Size:14.0"
Resolution:1920(RGB)×1080, FHD 157PPI
Brightness:400 cd/m² (Typ.)
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:309.31(W)×173.99(H) mm
Bezel Opening:-
Response Time:30 (Typ.)(Tr+Td)
Outline Size:315.81(W)×197.48(H) ×3(D) mm
Surface:Antiglare, Hard coating (3H)
Best View on:Symmetry
Display Colors:262K 100% sRGB
Lamp Type:10S5P WLED , 15K hours , With LED Driver
Frequency:60Hz
Touch Screen:Without
Application:Laptop
Signal Interface:eDP (2 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 30 pins Connector
Input Voltage:3.3V (Typ.)
Shape Style:Slim (PCBA Flat, T≤3.2mm)
