BOE NV140FHM-N4U LCD

Specification

Model P/N:NV140FHM-N4U
Brand:BOE
Diagonal Size:14.0"
Resolution:1920(RGB)×1080, FHD 157PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.2M 45% NTSC
Backlight:9S4P WLED , 15K hours , With LED Driver
Signal Type:eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:309.31(W)×173.99(H) mm
Bezel Opening:-
Treatment:Antiglare, Hard coating (3H)
Luminance:250 cd/m² (Typ.)
Outline(mm):315.8 × 186.048 × 5 (H×V×D)
Response:20 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:ADS, Normally Black, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline Shape:Slim (PCBA Bent, T≤3.0mm)
