NL2432HC22-44B NLT LCD panel replacement for Handheld & PDA

Panel Brand：NEC
Panel Size：3.5 inch
Resolution：240(RGB)×320 , QVGA
Display Area：53.64(W)×71.52(H) mm
Outline Size：63.5(W)×85(H)×5.7(D) mm
Brightness：200 cd/m2 (Typ.)
Viewing Angle：30/30/30/35 (Typ.)(CR≥10)
Best View on：-
Display Colors：262K40%(CIE1931)
Frequency： 60Hz
Weight：49.0/51.0g (Typ./Max.)
Panel Model：NL2432HC22-44B
Panel Type：a-Si TFT-LCD , LCM
Pixel Format： RGB Vertical Stripe
Bezel Opening：57.64(W)×76.52(H) mm
Surface：Clear, Hard coating (3H)
Contrast Ratio：150:1 (Typ.) (TM) 15:1 (Typ.) (RF)
Display Mode： TN, Normally White, Transflective
Response Time：7/23 (Typ.)(Tr/Td)
Lamp Type： 6S1P WLED , 50K hours , Without Driver
Touch Screen：Embeded (4-wire Resistive)
Application： Handheld & PDA,
Signal Interface： Parallel RGB (1 ch, 6-bit), 45 pins , Connector
Input Voltage： 3.0V (Typ.)
Environment： Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C; Vibration Level: 2.0G (19.6 m/s2)
