NEC NL10276BC30-04F LCD

Specification

Model P/N:NL10276BC30-04F
Brand:NEC
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Contrast Ratio:200 : 1 (Typ.) (TM)
Viewing Angle:60/60/40/50 (Typ.)(CR≥10)
Color Depth:262K 40% NTSC
Backlight:2 pcs CCFL , No Driver
Signal Type:LVDS (1 ch, 6-bit) , 20 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:308.8(W)×232.7(H) mm
Treatment:Hard coating (3H), Antireflection
Luminance:200 cd/m² (Typ.)
Outline(mm):350 × 265 × 19 (H×V×D)
Response:15/40 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:TBD
Used for:Desktop Monitor
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C ; Vibration Level: 2.0G (19.6 m/s²)
