BOE NE156QUM-N6C LCD

Specification

Model P/N:NE156QUM-N6C
Brand:BOE
Diagonal Size:15.6"
Resolution:3840(RGB)×2160, UHD 283PPI
Contrast Ratio:1500 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:1.06B 100% Adobe RGB
Backlight:WLED , 15K hours , With LED Driver
Signal Type:eDP (4 Lanes) , eDP1.4a , HBR2 (5.4G/lane) , 40 pins Connector
Panel Type:Oxide TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:344.218(W)×193.622(H) mm
Bezel Opening:-
Treatment:Antiglare, Hard coating (3H)
Luminance:600 cd/m² (Typ.)
Outline(mm):350.72 × 216.14 × 2.6 (H×V×D)
Response:25 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:ADS, Normally Black, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline Shape:Slim (PCBA Flat, T≤3.2mm)
