BOE NE156QHM-NY3 LCD

Specification

Model P/N:NE156QHM-NY3
Brand:BOE
Diagonal Size:15.6"
Resolution:2560(RGB)×1440, Quad-HD 188PPI
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:Oxide TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:344.22(W)×193.62(H) mm
Bezel Opening:-
Outline Dim:350.66(H)×216.14(V) ×2.6(D) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:300 cd/m² (Typ.)
View Direction:Symmetry
Response Time:9 (Typ.)(Tr+Td), 6 (Typ.)(G to G), 3 (Typ.)(G to G)(OD)
Operating Mode:ADS, Normally Black, Transmissive
Support Color:16.7M 100% sRGB
Light Source:WLED [10S5P] , 15K hours , With LED Driver
Designed For:Laptop ，Gaming
Frame Rate:165Hz
Touch Panel:Without
Interface Type:eDP (4 Lanes) , HBR2 (5.4G/lane) , 40 pins Connector
Power Supply:3.3V (Typ.)
Form Style:Slim (PCBA Flat, T≤3.2mm)
