CMO N141I1-L08 LCD

Specification

Model P/N:N141I1-L08 6
Brand:CMO
Diagonal Size:14.1"
Resolution:1280(RGB)×800, WXGA 107PPI
Contrast Ratio:700:1 (Typ.) (TM)
Viewing Angle:45/45/20/45 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:303.36(W)×189.6(H) mm
Bezel Opening:306.76(W)×193.0(H) mm
Outline Dim:319.5(H)×205.5(V) ×5.5(D) mm
Treatment:Glare (Haze 0%), Hard coating (3H), Reflection 2.0% (Max.)
Luminance:240 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:5/11 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 46% NTSC
Light Source:CCFL [1 pcs] , 15K hours , W/O Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 6-bit) , 30 pins Connector
Power Supply:3.3V (Typ.)
Form Style:Wedge (PCBA Bent, T≥5.2mm)
