CMO N141I1-L06 LCD

Specification

Model P/N:N141I1-L06 13
Brand:CMO
Diagonal Size:14.1"
Resolution:1280(RGB)×800, WXGA 107PPI
Contrast Ratio:600 : 1 (Typ.) (TM)
Viewing Angle:45/45/20/45 (Typ.)(CR≥10)
Color Depth:262K 46% NTSC
Backlight:1 pcs CCFL , 15K hours , No Driver
Signal Type:LVDS (1 ch, 6-bit) , Connector 30 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:303.36(W)×189.6(H) mm
Bezel Opening:306.76(W)×192.8(H) mm
Treatment:Antiglare (Haze 26%), Hard coating (3H)
Luminance:240 cd/m² (Typ.)
Response:5/11 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):319.5×205.5×5.5 (H×V×D)
Outline Shape:Wedge (PCBA Bent, T≥5.2mm)
