N140BGA-EA4 Innolux LCD panel replacement for Laptop

Panel Brand：Innolux
Panel Model：N140BGA-EA4 (CMN14D6)
Panel Size：14.0 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1366(RGB)×768 , WXGA
Pixel Format：RGB Vertical Stripe
Display Area：309.399(W)×173.952(H) mm
Bezel Opening：-
Outline Size：315.9(W)×205.1(H)×3(D) mm
Surface：Antiglare, Hard coating (3H)
Brightness：220 cd/m2 (Typ.)
Contrast Ratio：500:1 (Typ.) (TM)
Viewing Angle：45/45/20/45 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o’clock
Response Time：3/8 (Typ.)(Tr/Td)
Display Colors：262K 45%(CIE1931)
Lamp Type：WLED, 15K hours, With LED Driver
Frequency：60Hz
Touch Screen：Without
Shape Style： Slim (PCBA Flat, Depth ≤3.2mm)
Application： Laptop,
Signal Interface： eDP (1 Lane), 30 pins, Connector
Input Voltage：3.3V (Typ.)
Environment：Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
