Chimei Innolux N133I6-L10 LCD

Specification

Model P/N:N133I6-L10 8
Brand:Chimei Innolux
Diagonal Size:13.3"
Resolution:1280(RGB)×800, WXGA 113PPI
Brightness:345 cd/m² (Typ.)
Contrast Ratio:700:1 (Typ.) (TM)
Viewing Angle:70/70/55/55 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:286.08(W)×178.8(H) mm
Bezel Opening:-
Response Time:3/7 (Typ.)(Tr/Td)
Outline Size:307.44(W)×203.2(H) ×3.75(D) mm
Surface:Glare (Haze 0%), Hard coating (3H)
Best View on:6 o'clock
Display Colors:262K 72% NTSC
Lamp Type:WLED , 12K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Application:Laptop
Signal Interface:LVDS (1 ch, 6-bit) , 30 pins Connector
Input Voltage:3.3V (Typ.)
Shape Style:Flat (PCBA Flat, T3.4~4.0mm)
