CMO N133I6-L03 LCD

Specification

Model P/N:N133I6-L03 1
Brand:CMO
Diagonal Size:13.3"
Resolution:1280(RGB)×800, WXGA 113PPI
Contrast Ratio:400:1 (Typ.) (TM)
Viewing Angle:70/70/60/65 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:286.08(W)×178.8(H) mm
Bezel Opening:-
Luminance:410 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:5/11 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 50% NTSC
Light Source:WLED , 10K hours , W/O Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS (1 ch, 6-bit) , 30 pins Connector
Power Supply:3.3V (Typ.)
Form Style:Slim (PCBA Flat, T≤3.2mm)
