N116BGE-LB1 Innolux LCD panel replacement for Touchscreen

Manufacturer：Chimei Innolux
Model Name：N116BGE-LB1 (CMN1121)
Screen Size：11.6 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：1366(RGB)×768 (WXGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)：256.125 × 144 (H×V)
Outline(mm)： 278 × 168× 3.05 (H×V×D)
Bezel Area(mm)：259.13 × 146.8 (H×V)
Treatment：Glare (Haze 0%), Hard coating (3H)
Luminance：200 cd/m2 (Typ.)
Contrast Ratio：500 : 1 (Typ.) (TM)
Viewing Angle：45/45/20/45 (Typ.)(CR≥10)
Response：3/7 (Typ.)(Tr/Td) ms
Good View at：6 o’clock
Work Mode：TN, Normally White, Transmissive
Color Depth：262K 45%(CIE1931)
Backlight：WLED, 12K hours, With LED Driver
Outline Shape： Slim (PCBA Flat, Depth ≤3.2mm)
Used for： Laptop, Netbook PC,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： LVDS (1 ch, 6-bit), Connector , 40 pins
Voltage Supply：3.3V (Typ.)
Max. Ratings： Storage Temp.: -20 ~ 60 °COperating Temp.: 0 ~ 50 °C
