Chimei Innolux N101LGE-L21 LCD

Specification

Model P/N:N101LGE-L21 13
Brand:Chimei Innolux
Diagonal Size:10.1"
Resolution:1024(RGB)×600, WSVGA 117PPI
Brightness:200 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:45/45/20/45 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:222.72(W)×125.28(H) mm
Bezel Opening:226.34(W)×128.1(H) mm
Response Time:3/7 (Typ.)(Tr/Td)
Outline Size:235(W)×143(H) ×5.2(D) mm
Surface:Glare (Haze 0%), Hard coating (3H)
Best View on:6 o'clock
Display Colors:262K 45% NTSC
Lamp Type:WLED , 15K hours , With LED Driver
Frequency:60Hz
Touch Screen:Without
Application:Netbook PC
Signal Interface:LVDS (1 ch, 6-bit) , 40 pins Connector
Input Voltage:3.3V (Typ.)
Shape Style:Wedge (PCBA Bent, T≥5.2mm)
