Innolux N101L6-L02 LCD panel for Netbook PC

Panel Brand：CMO
Panel Model：N101L6-L02 (CMO1004) 13 Compatible
Panel Size：10.1 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1024(RGB)×600 , WSVGA
Pixel Format：RGB Vertical Stripe
Display Area：222.72(W)×125.28(H) mm
Bezel Opening：226.34(W)×128.1(H) mm
Outline Size：235(W)×143(H)×5.2(D) mm
Surface：Glare (Haze 0%), Hard coating (3H)
Brightness：200 cd/m2 (Typ.)
Contrast Ratio：650:1 (Typ.) (TM)
Viewing Angle：45/45/20/45 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o’clock
Response Time：3/7 (Typ.)(Tr/Td)
Display Colors：262K
Lamp Type：9S2PWLED, 15K hours, With LED Driver
Frequency： 60Hz
Touch Screen：Without
Shape Style： Wedge (PCBA Bent, Depth ≥5.2mm)
Application： Netbook PC,
Signal Interface： LVDS (1 ch, 6-bit), 40 pins , Connector
Input Voltage：3.3V (Typ.)
Environment： Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
