N080ICP-G01 Innolux LCD panel replacement for Pad & Tablet

Panel Brand：Innolux
Panel Size：8.0 inch
Resolution：800(RGB)×1280 , WXGA
Display Area：107.64(W)×172.224(H) mm
Outline Size：119.56(W)×188.9(H)×5.42(D) mm
Brightness：380 cd/m2 (Typ.)
Viewing Angle：89/89/89/89 (Min.)(CR≥10)
Best View on：Symmetry
Display Colors：16.7M
Frequency： 60Hz
Weight：151g (Max.)
Panel Model：N080ICP-G01
Panel Type：a-Si TFT-LCD , Assembly
Pixel Format： RGB Vertical Stripe
Bezel Opening：-
Surface：Hard coating (7H)
Contrast Ratio：800:1 (Typ.) (TM)
Display Mode： –
Response Time：25 (Typ.)(Tr+Td)
Lamp Type：WLED , 15K hours , Without Driver
Touch Screen：Embeded (Projected Capacitive Touch)
Application： Pad & Tablet,
Signal Interface： MIPI (4 data lanes), 39 pins , Connector
Input Voltage： 1.8/3.3V (Typ.)(VDDI/VCI)
Environment： Operating Temp.: -10 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
