Innolux N080ICE-GB0 Rev.B1 LCD panel

Brand：Innolux
Model：N080ICE-GB0 Rev.B1
Diagonal Size：8.0 inch
Type：a-Si TFT-LCD， LCM
Pixel Format：800(RGB)×1280[WXGA]
Configuration：RGB Vertical Stripe
Active Area：107.64(H)×172.224(V) mm
Outline Dim.：114.6(H)×184.1(V)×3.5(D) mm
Bezel Area：-
Treatment：Glare (Haze 0%)， Hard coating
Luminance：400 cd/m2 (Typ.)
Contrast Ratio：1000:1 (Typ.) (TM)
View Direction：Symmetry
Response Time：25 (Typ.)(Tr+Td)
Viewing Angle：85/85/85/85 (Typ.)(CR≥10)
Operating Mode：AAS， Normally Black， Transmissive
Support Color：16.7M 60%(CIE1931)
Light Source：WLED[3 strings]， 15K hours， W/O Driver
Weight：75.0g (Max.)
Designed For： Pad & Tablet,
Frame Rate： 60Hz
Touch Panel：Without
Interface Type： 39 pinsMIPI (4 data lanes)， Connector
Power Supply：1.8/3.3V (Typ.)(VDDI/VCI)
Environment：Operating Temperature: -10 ~ 60 °C; Storage Temperature: -20 ~ 70 °C
