BOE MV270FHB-NF0 LCD

Specification

Model P/N:MV270FHB-NF0
Brand:BOE
Diagonal Size:27.0"
Resolution:1920(RGB)×1080, FHD 81PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Color Depth:16.7M 99% sRGB
Backlight:No B/L
Signal Type:LVDS (4 ch, 8-bit) , Connector 92 pins
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:596.736(W)×335.664(H) mm
Bezel Opening:-
Treatment:Antiglare (Haze 25%), Hard coating (3H)
Luminance:0 cd/m²
Response:5 (Typ.)(G to G) ms
Good View at:Symmetry
Work Mode:ADS, Normally Black, Transmissive
Mass:TBD
Used for:Desktop Monitor ，Gaming
Refresh Rate:144Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):608.536×349.964 (H×V×D)
Driver IC list:Built-in COF 6 source chips
Transmissivity:5.7% (Typ.)(with Polarizer)
Glass Thickness:0.50+0.50 mm
