MT190AW02 V.V Innolux LCD panel replacement for Desktop Monitor

Panel Brand：Innolux
Panel Model：MT190AW02 V.V
Panel Size：19.0 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1440(RGB)×900 , WXGA+
Pixel Format：RGB Vertical Stripe
Display Area：408.24(W)×255.15(H) mm
Bezel Opening：412.24(W)×259.14(H) mm
Outline Size：428(W)×278(H)×16.5(D) mm
Surface：Antiglare (Haze 25%), Hard coating (3H)
Brightness：250 cd/m2 (Typ.)
Contrast Ratio：1000:1 (Typ.) (TM)
Viewing Angle：85/85/80/80 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o’clock
Response Time：1.5/3.5 (Typ.)(Tr/Td)
Display Colors：16.7M 72%(CIE1931)
Lamp Type：2 pcsCCFL, 50K hours, Without Driver
Frequency： 60Hz
Touch Screen：Without
Panel Weight： 2.20Kgs (Max.)
Application： Desktop Monitor,
Signal Interface： LVDS (2 ch, 8-bit), 30 pins , Connector
Input Voltage：5.0V (Typ.)
Environment： Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C
