Innolux MT170EN01 V.9 LCD panel for Desktop Monitor

Panel Brand：Innolux
Panel Model：MT170EN01 V.95 Compatible
Panel Size：17.0 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1280(RGB)×1024 , SXGA
Pixel Format：RGB Vertical Stripe
Display Area：337.92(W)×270.336(H) mm
Bezel Opening：341.6(W)×274.0(H) mm
Outline Size：358.5(W)×296.5(H)×17.5(D) mm
Surface：Antiglare (Haze 25%), Hard coating (3H)
Brightness：300 cd/m2 (Typ.)
Contrast Ratio：800:1 (Typ.) (TM)
Viewing Angle：80/80/80/80 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：-
Response Time：1/4 (Typ.)(Tr/Td)
Display Colors：16.7M 72%(CIE1931)
Lamp Type：4 pcsCCFL, 50K hours, Without Driver
Frequency：60Hz
Touch Screen：Without
Panel Weight： 2.25Kgs (Max.)
Application： Desktop Monitor,
Signal Interface： LVDS (2 ch, 8-bit), 30 pins, Connector
Input Voltage：5.0V (Typ.)
Environment：Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -25 ~ 60 °C
