AUO M270HW01 V0 LCD panel for Desktop Monitor

Brand：AUO
Model：M270HW01 V0
Diagonal Size：27.0 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1920(RGB)×1080[FHD]
Configuration：RGB Vertical Stripe
Active Area：597.6(H)×336.15(V) mm
Outline Dim.：630(H)×368.2(V) mm
Bezel Area：603.9(H)×342.15(V) mm
Treatment：Antiglare, Hard coating (3H)
Luminance：400 cd/m2 (Typ.)
Contrast Ratio：1000:1 (Typ.) (TM)
View Direction：6 o'clock
Response Time：3.8/1.2 (Typ.)(Tr/Td)
Viewing Angle：85/85/80/80 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：16.7M 72%(CIE1931)
Light Source：CCFL[4 pcs], 50K hours, W/O Driver
Weight： 3.80Kgs
Designed For： Desktop Monitor,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 30 pinsLVDS (2 ch, 8-bit), Connector
Power Supply：5.0V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
