AUO M238DAN01.7 LCD

Specification

Model P/N:M238DAN01.7
Brand:AUO
Diagonal Size:23.8"
Resolution:2560(RGB)×1440, Quad-HD 123PPI
Brightness:300 cd/m² (Typ.)
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:526.85(W)×296.35(H) mm
Bezel Opening:-
Response Time:14 (Typ.)(G to G)
Outline Size:534.64(W)×312.78(H) ×11.9(D) mm
Surface:Antiglare (Haze 25%), Hard coating (3H)
Best View on:Symmetry
Display Colors:16.7M 94% DCI-P3
Lamp Type:20S4P WLED , 30K hours , Without Driver
Frequency:75Hz
Touch Screen:Without
Panel Weight:1.50/1.58Kgs (Typ./Max.)
Application:Desktop Monitor
Signal Interface:LVDS (4 ch, 8-bit) , 70 pins Connector
Input Voltage:5.0V (Typ.)
