AUO M238DAN01.0 LCD

Specification

Model P/N:M238DAN01.0
Brand:AUO
Diagonal Size:23.8"
Resolution:2560(RGB)×1440, Quad-HD 123PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:89/89/89/89 (Typ.)(CR≥10)
Color Depth:16.7M 100% sRGB
Backlight:15S4P WLED , 30K hours , No Driver
Signal Type:LVDS (4 ch, 8-bit) , Connector 92 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:526.85(W)×296.35(H) mm
Bezel Opening:530.2(W)×299.6(H) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:300 cd/m² (Typ.)
Response:14 (Typ.)(G to G) ms
Good View at:Symmetry
Work Mode:AHVA, Normally Black, Transmissive
Mass:2.31Kgs (Typ.)
Used for:Desktop Monitor
Refresh Rate:75Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):543×317.4×14 (H×V×D)
