Chimei Innolux M200FGE-L20 LCD

Specification

Model P/N:M200FGE-L20
Brand:Chimei Innolux
Diagonal Size:20.0"
Resolution:1600(RGB)×900, HD+ 91PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:85/85/80/80 (Typ.)(CR≥10)
Color Depth:16.7M 72% NTSC
Backlight:10S4P WLED , 50K hours , No Driver
Signal Type:LVDS (2 ch, 8-bit) , 30 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:442.8(W)×249.075(H) mm
Bezel Opening:446.8(W)×253.2(H) mm
Treatment:Antiglare (Haze 25%), Hard coating (3H)
Luminance:250 cd/m² (Typ.)
Outline(mm):462.8 × 272 × 11 (H×V×D)
Response:1.5/3.5 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:1.63/1.80Kgs (Typ./Max.)
Used for:Desktop Monitor
Refresh Rate:75Hz
Touchscreen:Without
Voltage Supply:5.0V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
