AUO M185XTN01.2 CELL LCD

Specification

Model P/N:M185XTN01.2 CELL
Brand:AUO
Diagonal Size:18.5"
Resolution:1366(RGB)×768, WXGA 84PPI
Brightness:0 cd/m²
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:85/85/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:409.8(W)×230.4(H) mm
Bezel Opening:-
Response Time:3.6/1.4 (Typ.)(Tr/Td)
Best View on:-
Display Colors:16.7M 72% NTSC
Lamp Type:No B/L
Frequency:75Hz
Touch Screen:Without
Panel Weight:410g (Typ.)
Application:Desktop Monitor
Signal Interface:LVDS (1 ch, 8-bit) , 30 pins Connector
Input Voltage:5.0V (Typ.)
Driver IC:COFBuilt-in 4 source chips
Glass Depth:-
Transmissivity:6.8% (Typ.)(with Polarizer)
