CMO M170E4-L01 LCD

Specification

Model P/N:M170E4-L01 1
Brand:CMO
Diagonal Size:17.0"
Resolution:1280(RGB)×1024, SXGA 96PPI
Brightness:250 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:337.92(W)×270.336(H) mm
Bezel Opening:342.0(W)×274.5(H) mm
Response Time:15/10 (Typ.)(Tr/Td)
Outline Size:383.5(W)×306(H) ×20.5(D) mm
Surface:Antiglare (Haze 25%), Hard coating
Best View on:Symmetry
Display Colors:16.2M 68% NTSC
Lamp Type:4 pcs CCFL , 50K hours , Without Driver
Frequency:75Hz
Touch Screen:Without
Panel Weight:2.20Kgs (Typ.)
Application:Desktop Monitor
Signal Interface:LVDS (2 ch, 8-bit) , 30 pins Connector
Input Voltage:5.0V (Typ.)
