M133NWN1 R4 IVO LCD panel replacement for Touch Panel

Brand：IVO
Model：M133NWN1 R4 (IVO0533)
Diagonal Size：13.3 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1366(RGB)×768[WXGA]
Configuration： RGB Vertical Stripe
Active Area：293.42(H)×164.97(V) mm
Outline Dim.：306.3(H)×195.2(V)×3(D) mm
Bezel Area：-
Treatment：Antiglare, Hard coating (3H)
Luminance：200 cd/m2 (Typ.)
Contrast Ratio： 500:1 (Typ.) (TM)
View Direction：6 o’clock
Response Time：8 (Typ.)(Tr+Td)
Viewing Angle：45/45/20/40 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K 45%(CIE1931)
Light Source：WLED, 15K hours, With LED Driver
Form Style： Slim (PCBA Flat, Depth ≤3.2mm)
Designed For： Laptop,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 30 pinseDP (2 Lanes), Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
